| Image Sensor |
1/2.8’’ 2.0MP Progressive Scan CMOS |
| Max. Resolution |
2.0 Megapixel |
| Effective Pixels |
|
| RAM / ROM |
|
| Ultra Low Light Colour |
Yes |
| Min Illumination |
0.005 Lux/F1.8 (Color), 0.0005 Lux/F1.8(B/W) 0 Lux/F1.8 (IR on) |
| S/N Ratio |
Infrared |
| Infrared |
Yes |
| Infrared System |
1 x Infrared LED, 35m range, Auto/manual on/off control |
| Lens Type |
Fixed |
| Lens / Iris |
|
| Field of View |
Horizontal: 80°, Vertical: 45° |
| Focus |
Fixed |
| DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.) |
| Detect (25px/m) |
Person: 146m / Vehicle: 389m |
| Observe (63px/m) |
Person: 57m / Vehicle: 153m |
| Recognise (125px/m) |
Person: 38m / Vehicle: 97m |
| Identify (250px/m) |
Person: 19m / Vehicle: 49m |
| Thermal Camera |
|
| Thermal Sensor |
Uncooled VOx Microbolometer |
| Effective Pixels (Thermal) |
|
| Sensitivity (NETD) |
<50mK@f/1.1 |
| Spectral Range |
8~14?m |
| Image Settings |
Brightness, Sharpness, Region of Interest, Auto Gain Control, Flat Field Correction, 3D Digital Noise Reduction |
| Colour Palettes |
18 thermal colour palettes (eg: WhiteHot, BlackHot, Rainbow etc.) |
| Lens / Iris (Thermal) |
|
| Field of View (Thermal) |
Horizontal: 50.6°, Vertical: 37.8° |
| Focus (Thermal) |
|
| Video |
|
| Resolution |
1080p (1920 x 1080) to CIF (256 x 192) |
| Frame Rate (Main) |
Visible: 50Hz 1920 x 1080 to 704 x 576 (1~25fps) / Thermal: 50Hz 1280 x 960 to 256 x 192 (1~25fps) |
| Frame Rate (Sub) |
Visible: 50Hz 704 x 576 to 352 x288 (1~25fps) / Thermal: 50Hz 640 x 480 to 256 x 192 (1~25fps) |
| Frame Rate (Third) |
N/A |
| Video Compression |
H.265 / H.264M / H.264H / H.264B / MJEG |
| Bit Rate |
|
| Bit Rate Control |
Constant bit rate (CBR) / Variable bit rate (VBR) |
| Day/Night |
|
| Lighting Compensation |
|
| White Balance |
Auto / Indoor / Outdoor / Manual etc. |
| Gain Control |
Auto / Manual |
| Noise Reduction |
2D/3D DNR |
| Picture Control |
|
| IVS |
|
| IVS |
Yes |
| Intelligent Functions |
|
| Thermal Functions |
Fire detection & alarm, cold/hot spot trace, human/vehicle classification, smoke detection |
| Network |
|
| Ethernet |
|
| Protocol |
HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPOE,IPv4/v6, SNMP, QoS, UPnP, NTP |
| Streaming Method |
|
| Max. User Access |
20 users |
| RTMP Support |
No |
| Interface |
|
| Video Interface |
1 Port BNC |
| Audio Interface |
|
| Alarm Interface |
|
| RS485 |
Support |
| Edge Storage |
MicroSD Card (up to 256GB) / memory status display (normal/error/active/lock/formatting) / NAS / Local PC |
| Interoperability |
|
| Environmental |
|
| Power Supply |
12VDC / PoE |
| Power Consumption |
<12W |
| Operating Conditions |
-30° ~ +60° C / Less than 95% RH |
| Ingress Protection |
IP67 |
| Weather Resistance |
Yes |
| Vandal Resistance |
No |
| Series |
|
| Camera Type |
Bullet |
| Housing |
Metal |
| Pan/Tilt/Rotation |
N/A |
| Tri-Axis Mounting |
No |
| ePoE |
No |
| Dimensions |
280mm x 104mm x 96mm (with bracket) |
| Net Weight |
1.4kg |
| Warranty (Years) |
4 |
