Description
Engineered by Uniview, one of the world's leading video surveillance innovators, Uniview can meet your security needs in different scenarios. Their IP cameras renders high-quality images even in low illumination environment while featuring smart functions based on video content analytics, and minimizing bandwidth and storage. The most important business value of them is to provide excellent performance at an affordable price.
Prime Series
It is unbelievable that you can always find ideal products in UNV Prime series which has more advanced functions to implement excellent performance. Prime series contains standard and enhanced cameras and NVRs which have a wide range of smart functions, resolutions and high-quality video content intelligent analysis. Various mainstream resolutions such as 2/4/5/8MP are available for whole series and can present different levels of image quality. VCA of recorders, including face detection, intrusion detection, and defocus detection, are able to improve management efficiency greatly. Therefore, products from Prime family are commonly used in commercial building, park, and small project application to effectively guarantee security.
Features
- 33X Optical Zoom
- Starlight illumination
- Accurate and fast focusing
- Smart IR, up to200 m (656ft) IR distance
- Up to 120 dB WDR(Wide Dynamic)
- IR anti-reflection window to increase the infrared transmittance
- Ultra 265,H.265, H.264, MJPEG
- Embedded smart algorithm
- Triple streams
- Customized OSD
- ONVIF Conformance
- 15° Elevation Angle
- Innovative snow-removing functionality
- More effective heat dissipation system
- Intelligent temperature control technology
- 6 KV surge protection designed for network interface
- Starlight illumination
- Accurate and fast focusing
- Smart IR, up to250 m (820ft) IR distance
- Optical glass window with higher light transmittance
- IR anti-reflection window to increase the infrared transmittance
- Ultra 265,H.265, H.264, MJPEG
- Embedded smart algorithm
- Triple streams
- Customized OSD
- ONVIF Conformance
- Optional network interfaces with Ethernet RJ45 andoptical SFP
- Innovative snow-removing functionality
- More effective heat dissipation system
- Intelligent temperature control technology
- IP66
Datasheet
Videos
Tech Specs
Uniview Security Camera: 2MP Dome PTZ, 5.7-216.6mm, Prime - IPC6852SR-X38UG
| IPC6252SL-X33UP |
| Camera |
| Sensor |
1/2.8″, progressive scan,2.0 megapixel, CMOS |
| Lens |
4.5 ~ 148.5 mm, AF automatic focusing and motorized zoom lens |
| Digital Zoom |
16 |
| Optical Zoom |
33 |
| DORI Distance |
Lens |
Detect(m) |
Observe(m) |
Recognize(m) |
Identify(m) |
| 4.5mm |
69.8 |
27.9 |
14 |
7 |
| 148.5mm |
2304.3 |
921.7 |
460.9 |
230.4 |
| Angle of View(H) |
62.67°~2.82° |
| Angle of View (V) |
38.4°~1.3° |
| Angle of View (O) |
77.1°~3.3° |
| Shutter |
Auto/Manual, shutter time: 1 ~ 1/100000 s |
| Minimum Illumination |
Colour: 0.002 lux (F1.6, AGC ON)
0 lux with IR |
| Iris |
Auto/Manual, F1.6 ~ F5.3 |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Digital noise reduction |
2D/3D DNR |
| S/N |
>52dB |
| VF laser |
Up to 500m(1640 ft) |
| Defog |
Digital Defog |
| WDR |
120dB |
| Video |
| Video Compression |
Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile, High Profile |
| Frame Rate |
Main Stream:2MP (1920×1080):Max. 60 fps;
Sub Stream:2MP (1920×1080):Max. 60 fps;
Third Stream: D1 (720×576): Max. 60 fps |
| HLC |
Supported |
| BLC |
Supported |
| EIS |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 24 areas |
| ROI |
Up to 8 areas |
| Motion Detection |
Up to 4 areas |
| Smart |
| Behavior Detection |
Intrusion, cross line, motion detection, Auto tracking |
| Intrusion |
Enter and loiter in a pre-defined virtual region |
| cross line |
Cross a pre-defined virtual line |
| motion detection |
Moving within a pre-defined virtual region |
| auto tracking |
Tracking the specified target |
| Recognition |
Face detection、Audio detection |
| Intelligent Identification |
Defocus, Scene Change, Object Left, Object Moving |
| Statistical Analysis |
People counting |
| General Function |
Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression |
G.711 |
| Two-way Audio |
Supported |
| Suppression |
Supported |
| Sampling Rate |
8 KHZ |
| Storage |
| Edge Storage |
Micro SD, up to 256 GB |
| Network Storage |
ANR |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP,SSL |
| Compatible Integration |
ONVIF(Profile S, Profile G, Profile T),API |
| Pan & Tilt |
| Pan Range |
360° |
| Pan Speed |
0.1°/s ~ 240°/s |
| Preset speed: 300°/s |
| Tilt Range |
–15° ~ +90° (auto reverse) |
| Tilt Speed |
0.1° ~ 160°/s |
| Preset speed: 240°/s |
| Number of Presets |
1024 |
| Patrol |
Preset patrol, route patrol, recorded patrol |
| Home Position |
Supported |
| Interface |
| Audio I/O |
Audio interface |
| 1 Input: impedance 35 kΩ; amplitude 2 V [p-p] |
| 1 Output: impedance 600 Ω; amplitude 2 V [p-p] |
| Alarm I/O |
1/ 1 |
| Network |
1 RJ45 10M/100M Base-TX adaptive Ethernet network interface |
| General |
| Power |
24 V AC±25% (default power supply), 24V DC±25%, PoE (PSE Required) |
| Power consumption: 8 W ~ 47 W |
| Dimensions (Ø x H) |
Ø227 mm x 359.4 mm (Ø8.9″ x 14.2″) |
| Weight |
5.6 kg (12.3 lb) |
| Working Environment |
–40°C ~ +70°C (-40°F ~ 158°F), Humidity:10%~95% RH(non-condensing) |
| Ingress Protection |
IP66 |
| IR |
Built-in VF laser IR |
| Reset Button |
Supported |
