Description
The Uniview NSW2000-8T1GC-POE is an 8-port PoE switch, which provides 8 10/100Mbps PoE ports and 1 Gigabit combo port. All ports support wire speed, non-blocking switching and auto MDI/MDIX. Besides common switch features, NSW2000-8T1GC-POE supports EXTEND mode especially for video surveillance. When EXTEND mode is enabled, the transmission distance with Uniview IPC can reach up to 250m.
Features
-
8×10/100Mbps Ethernet ports
- 1×Gigabit combo port (RJ45 and SFP)
- All 100Mbps ports support PoE
- PoE complies with IEEE802.3af/at, up to 30W for single port
-
Up to 250m transmission distance on EXTEND mode
- Easy to use, no need to configure
-
High quality with all metal housing
- WARRANTY: 3 years back-to-base manufacturer warranty
Tech Specs
NSW2000-8T1GC-POE
| Item |
Information |
| Ports |
8×10/100Base-TX autosensing Ethernet ports(all support PoE)
1×Gigabit combo port (RJ45 and SFP) |
| Port attribute |
10/100/1000Mbit/s transfer rate
Half-duplex, full-duplex and auto-negotiation
Auto MDI/MDIX |
| Standards |
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-X
ANSI/IEEE 802.3 NWay
IEEE 802.3x flow control
IEEE 802.3af PoE
IEEE 802.3at PoE |
| MAC |
4K |
| Packet forwarding rate |
2.68Mpps |
| Switching capacity |
3.6Gbps |
| EXTEND mode |
Disabled: all ports can communicate with each other, and monitoring optimization is disabled.
Enabled: Downlink ports can only communicate with uplink ports, monitoring optimization is enabled, and transmission distance can be extended to up to 250 meters. |
| Status LEDs |
Link/Act (steady green): link is normal
Link/Act (flashing green): data is being forwarded
Link/Act (off): no link |
PoE (steady orange): the port is powering a powered device properly
PoE (off): the port is not connected to any powered device or is not supplying power |
Power (steady green): AC input is normal
Power (off): AC input is abnormal |
| PoE |
802.3at/af
Max PoE capacity: 115 W |
| Consumption |
? 120 W |
| DC voltage |
54 V , 2.2A |
| Operating temperature |
0°C-40°C (32°F-104°F) |
| Operating humidity |
10%-85% |
| Storage temperature |
-10°C-70°C (14°F-158°F) |
| Storage humidity |
10%-90% |
| Dimensions (W×D×H) |
235mm × 110mm × 27mm (9.3"× 4.3"× 1.1") |
