Description
StreetSiren DoubleDeck is a wireless outdoor siren with mount for the branded faceplate. Equipped with a LED frame and piezoelectric alarm indicator producing sound volume up to 113 dB, StreetSiren can operate up to 5 years from pre-installed batteries. It can also be powered from an external 12 V power supply.
StreetSiren DoubleDeck communicates with the hub via the secured Jeweller radio protocol. The communication range is up to 1,500 meters provided there are no obstacles.
Features
- To attract attention
- To indicate the system state
- Right protection for every setting
- Weatherproof
- Protected from vandals
- Effortless maintenance
- Installation without pitfalls
Complete Set
- StreetSiren DoubleDeck
- SmartBracket mounting panel
- CR123A battery (pre-installed) — 4 pcs
- Mounting kit
- Quick Start Guide
More info about StreetSiren DoubleDeck (White) on Ajax website: https://ajax.systems/products/streetsiren-doubledeck/
Download
Video
Tech Specs
StreetSiren DoubleDeck (White)
| Siren type |
Wireless |
| Type of notification |
Sound and light |
| Installation method |
Indoor / Outdoor |
| Brandplate material |
Plastic |
| Brandplate installation method |
Clip lock and mounting screw |
| Notification volume |
85–113 dB at a distance of 1 m (adjustable) |
| Alarm sounding time |
Adjustable, 3 to 180 seconds |
| Siren Sound Alert Frequency |
3.5 ± 0.5 kHz |
| Protection against dismantling |
Accelerometer and tampers for violation of the integrity of the body |
| Compatibility |
Operates only with all Ajax hubs, and radio signal range extenders
|
| Arming/disarming status indication |
Available |
| Indication of delays when entering/leaving |
Available |
| Radio communication protocol |
Jeweller
Learn more
|
| Radio frequency band |
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
Depends on the region of sale. |
| Maximum RF output power |
7.29 mW (max 25 mW) |
| Radio signal range |
Up to 1,500 m (any obstacles absent)
Learn more
|
| Power supply |
4 × CR123A, 3 V |
| Battery life |
Up to 5 years
Learn more
|
| Auxiliary power supply |
12 V DC, 1,5 A |
| Body protection level |
IP54 |
| Operating temperature range |
From –25°С to +50°С |
| Operating humidity |
Up to 95% |
| Dimensions |
200 × 200 × 55 mm |
| Weight |
571 g |
| Service life |
10 years |
2-Years Warranty
Ajax’s 2-year manufacturer warranty covers defects in materials or errors in the manufacturing process that may occur within 24 months from the date of sale. The warranty does not cover normal wear and tear (device body scrapes, scratches, etc.), wear of the elements caused by improper operation, and normal wear of the device components, mechanical and/or electrical damage (including latent), exposure to direct sunlight, high humidity, and vibration or damage caused by natural disasters.
The warranty does not cover damage to the product resulting from unauthorised repair, installation, and/or replacement of components or programs, including the installation of updates and extensions, performed by anyone other than an authorised representative of the Limited Liability Company “Ajax Systems Manufacturing”.
If a device is faulty, SpyMonkey will facilitate the warranty process with the manufacturer for you. We aim to do so in a manner that is as fast and efficient as possible.
Please contact our support team at support@SpyMonkey.com.au or 1300-049-519.
Please note, that we do not cover inbound shipping of the return to us however if a replacement is to be sent we will cover outbound shipping to the customer. We will need the serial number of the product and your order number.
Please don’t ship us anything until you have had confirmation from our teams and they have given you an RMA number and return address.
Wireless outdoor siren with a clip lock for a branded faceplate (White)
Please note: Brandplates are sold separately
