| VIDEO |
| Imaging Device |
1/2.8" 2.16M CMOS |
| Total Pixels |
1,945(H) x 1,109(V), 2.16M |
| Effective Pixels |
1,945(H) x 1,097(V), 2.13M |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.015 Lux (1/30sec, F1.4), B/W : 0.0015 Lux (1/30sec, F1.4) |
| S / N Ratio |
50dB |
| Video Out |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for Installation
USB : Micro USB Type B, 1280 x 720 for Installation |
| LENS |
| Focal Length (Zoom Ratio) |
2.8 ~ 12mm (Optical 4.3x) |
| Max. Aperture Ratio |
F1.4 |
| Angular Field of View |
H : 119.5° ~ 27.9°, V : 62.8° ~ 15.7°, D : 142.1° ~ 32.0° |
| Min. Object Distance |
1.5m (4.92ft) (Wide), 2m (6.56ft) (Tele) |
| Focus Control |
Auto / Manual / One Push |
| Lens / Mount Type |
DC Auto Iris / Board-in type |
| PAN/TILT/ROTATE |
| Pan Range / Speed |
0° ~ 350° / 0.1°/sec ~60°/sec |
| Tilt Range / Speed |
0° ~ 90° / 0.1°/sec ~ 60°/sec |
| Sequence / Preset Accuracy |
Preset (300ea), Swing, Group (6ea), Trace, Tour (1ea), Auto Run, Schedule / ± 0.5° |
| Azimuth |
Yes (E / W / S / N / NE / NW / SE / SW) |
| Auto Tracking |
Support |
| OPERATIONAL |
| Camera Title |
Off / On (Displayed up to 85 Characters)
- W/W : English / Numeric / Special Characters
- China : English / Numeric / Special / Chinese Characters
- Common : Multi-line (Max. 5), Color (Gray / Green / Red / Blue / Black / White), Transparency, Auto scale by Resolution |
| Day & Night |
Auto (ICR) / Color / B/W |
| Backlight Compensation |
Off / BLC / HLC / WDR |
| Wide Dynamic Range |
150dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNRV (2D + 3D Noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On (Built-in Gyro sensor) |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (8ea, 8point Polygonal zones) |
| Privacy Masking |
Off / On (24ea, Rectangle zones)
- Color : Gray / Green / Red / Blue / Black / White
- Zoom ratio option for mask mode - Mosaic |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (included Mercury & Sodium) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital Zoom |
24x, area zoom function support digital zoom 2x |
| Flip / Mirror |
Off / On |
| Video & Audio Analytics |
Tampering, Loitering, Directional detection, Defocus detecion, Fog detection, Virtual line, Enter/Exit, (Dis) Appear, Audio detection, Face detection, Motion detection, Digital auto tracking, Sound classification |
| Serial Interface |
RS-485 - Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Motion detection, Tampering, Audio detection, Face detecton, Video analytics, Alarm input, Network disconnection |
| Alarm Events |
File upload Via FTP, E-Mail, Notification Via E-Mail, Local storage (SD/SDHC/SDXC) or NAS recording at event triggers, External output, preset |
| Pixel Counter |
Support |
| NETWORK |
| Ethernet |
RJ-45 (10/100 BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265/H.264 : Max 60fps at all resolutions, MJPEG : Max. 30fps at all resolutions |
| Smart Codec |
Manual mode (Area-based : 5ea) |
| WiseStreamII |
Support |
| Video Quality Adjustment |
H.265 / H.264 / MJPEG : Target Bitrate Level Control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple Streaming (Up to 10 Profiles) |
| Audio In |
Selectable (Mic in / Line in), Supply Voltage : 2.5V DC (4mA), Input Impedance : Approx. 2K Ohm |
| Audio Out |
Line out (3.5mm mono jack), Max output level : 1 Vrms |
| Audio Compression Format |
G.711 u-law /G.726 Selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz |
| Audio Communication |
Bi-dierctional |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log, 802.1X Authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users at Unicast Mode |
| Edge Storage |
SD/SDHC/SDXC 2slot (up to 512 GB)
- Continuous recording (1'st slot to 2'nd slot)
- Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded.
NAS (Network Attached Storage), Local PC for Instant Recording |
| Application Programming Interface |
ONVIF profile S/G, SUNAPI 2.0 (HTTP API), Wisenet Open Platform |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Russian, Japanese, Swedish, Portuguese, Turkish, Polish, Czech, Dutch, Hungary, Greek |
| Web Viewer |
Supported OS : Windows 7, 8, 10, Mac OS X 10.10, 10.11, 10.12
Non-plugin Webviewer
- Supported Browser: Google Chrome, MS Edge, Mozilla Firefox , Apple Safari 10
(Mac OS X only)
Plug-in Webviewer
- Supported Browser : MS Explore 11, Apple Safari 10 (Mac OS X only) |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Ingress Protection / Vandal Resistance |
IP66 / IK10 |
| ELECTRICAL |
| Input Voltage / Current |
12V DC, PoE |
| Power Consumption |
Max. 8.6W (12V DC), Max. 9.6W (PoE) |
| MECHANICAL |
| Color / Material |
Ivory / Aluminum |
| Dimensions (WxH) |
Ø136.1 x 106.1mm (Ø5.36" x 4.18") |
| Weight |
0.78 kg (1.72 lb) |
