| Video |
| Imaging Device |
1/2.8" 2.38M CMOS |
| Total Pixels |
1,952(H) x 1,116(V) |
| Effective Pixels |
1,944(H) x 1,104(V) |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.1Lux (F1.2, 50IRE), 0.03Lux (F1.2, 30IRE)
B/W : 0.01Lux (F1.2, 50IRE), 0.002Lux (F1.2, 30IRE) |
| S / N Ratio |
50dB |
| Video Output |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type |
| Lens |
| Focus Control |
Simple focus / Manual, Remote control via network (Manual, Simple focus, Day & Night) |
| Lens Type |
Manual / DC auto iris, P-Iris |
| Mount Type |
C / CS |
| Operational |
| Camera Title |
Off / On (Displayed up to 45 characters) |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC / WDR |
| Wide Dynamic Range |
120dB |
| Contrast Enhancement |
SSDR (Samsung Super Dynamic Range) (Off / On) |
| Digital Noise Reduction |
SSNRIII (2D+3D noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (4 zones with 4-sided polygon) |
| Privacy Masking |
Off / On (32 zones with 4-sided polygon) |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Flip / Mirror |
Off / On |
| Intelligent Video Analytics |
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection with Metadata |
| Alarm I/O |
Input 1ea / Output 1ea |
| Remote Control Interface |
RS-485 |
| RS-485 Protocol |
Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch |
| Alarm Triggers |
Motion detection, Tampering, Audio detection, Face detecton, Video analytics, Alarm input, Network disconnection |
| Alarm Events |
File upload via FTP and E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at Event, External output |
| Netw ork |
| Ethernet : Fiber |
SFP (LC type) |
| Fiber : Ethernet Physical Layer |
100 Base-FX, 1000 Base-X |
| Fiber : Default Speed |
1000Mbps |
| Fiber : Ethernet Standard |
IEEE 802.3u, IEEE 802.3z support |
| Video Compression Format |
H.264 (MPEG-4 part 10/AVC), MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| Max. Framerate |
H.264 : Max. 60fps at all resolutions
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps |
| Smart Codec |
Manual mode (Area-based : 5ea), Face detection mode |
| Video Quality Adjustment |
H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method |
H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 profiles) |
| Audio In |
Selectable (Mic in / Line in), Built-in mic.
Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio Out |
Line out (3.5mm stereo mini jack), Max output level : 1 Vrms |
| Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| Audio Communication |
Bi-directional audio |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
15 users at unicast mode |
| Edge Storage |
micro SD/SDHC/SDXC - motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage) |
| Application Programming Interface |
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
| Web Viewer |
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10
Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11)
Mozilla Firefox (Ver. 9 ~ 35), Google Chrome (Ver. 15 ~ 40)
Apple Safari (Ver. 8.0.2 (Mac OS X 10.10), 7.0.6 (Mac OS X 10.9),
6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
| Central Management Software |
SmartViewer, SSM |
| Envir onmental |
| Operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Electrical |
| Input Voltage / Current |
24V AC ±10%, 12V DC ±10% |
| Power Consumption |
Max. 12.5W (24V AC, 50 ~ 60Hz), Max. 10.5W (12V DC) |
| Mechanical |
| Color / Material |
Black, Ivory / Aluminium, Plastic |
| Dimensions (WxHxD) |
73.1 x 66.6 x 147.8mm (2.88" x 2.62" x 5.82") |
| Weight |
385g (0.85 lb) |
