Professional, intelligent |
Perimeter Protection |
Tripwire; intrusion; loitering detection; people gathering. |
People Counting |
Entry number and exit number counting: Support configuring 4 rules, and display and output Entry number and exit number counting: Support configuring 4 rules, and display and output daily/monthly/annual report People counting in the area: Support configuring 4 rules Queue management: Support configuring 4 rules, and count the number of people and strand time, and link alarm |
Intelligent Search |
Work together with Smart NVR to perform refine the intelligent search, event extraction and merging to event videos. |
Video |
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG |
Smart Codec |
H.264: Yes H.265: Yes |
Video Frame Rate |
50 Hz: Main Stream: 2688 × 1520 @25 fps; sub stream: 704 × 576 @25 fps; third stream: 704 × 576 @25 fps Main Stream: 2688 × 1520 @25 fps; sub stream: 704 × 576 @25 fps; third stream: 1920 × 1080 @11 fps 60 Hz: Main Stream: 2688 × 1520 @30 fps; sub stream: 704 × 480 @30 fps; third stream: 704 × 480 @12 fps Main Stream: 2688 × 1520 @30 fps; sub stream: 704 × 480 @30 fps; third stream: 1920 × 1080 @1 fps |
Stream Capability |
3 streams |
Resolution |
2688 × 1520; 2560 × 1440; 2304 × 1296; 2016 × 1512; 1080p (1920 × 1080); UXGA(1600 × 1200); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF(352 × 288/352 × 240) |
Bit Rate Control |
CBR; VBR |
Video Bit Rate |
H.264: 32 Kbps–8192 Kbps
H.265: 19 Kbps–8192 Kbps
|
Day/Night |
ICR switch |
BLC |
Yes |
WDR |
140 dB |
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
Gain Control |
Manual/Auto |
Noise Reduction |
3D DNR |
Motion Detection |
OFF/ON (4 areas, rectangular) |
Region of Interest(RoI) |
Yes (4 areas) |
Electronic Image Stabilization(EIS) |
Yes |
Smart IR |
Yes (Adjust by user) |
Defog |
Yes |
Image Rotation |
0°/90°/180°/270° |
Mirror |
Yes |
Privacy Masking |
4 areas |
Audio |
Built-in MIC |
Yes |
Audio Compression |
G.711a; G.711Mu; G726; AAC |
Network |
Network |
RJ-45 (10/100 Base-T) |
Protocol |
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP |
Interoperability |
ONVIF (Profile S/Profile G); CGI; Milestone; Genetec; P2P |
Scene self-adaptation |
Yes |
User/Host |
20 (Total bandwidth: 80 M.) |
Edge Storage |
FTP; NAS; Micro SD card (support max. 256 G) |
Browser |
IE: Versions later than IE 8 Google Firefox Apple: versions later than Safari 12 |
Management Software |
Smart PSS; DSS; P2P |
Mobile Phone |
IOS, Android |
Certification |
Certifications |
CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU CE-RED: Radio Equipment Directive 2014/53/EU FCC: 47 CFR FCC Part 15, Subpart B FCC ID: FCC PART 15C |
Port |
RS-485 |
1 (Baud rate range: 1200 bps–115200 bps) |
Audio Input |
1 channel (Terminal) |
Audio Output |
1 channel (Terminal) |
Alarm Input |
1 channel in: 5mA 3V–5V DC |
Alarm Output |
1 channel out: 300mA 12V DC |
Power |
Power Supply |
12V DC/PoE |
Power Consumption |
Basic power consumption: 3W (12V DC); 3.6W (PoE) Max. power consumption (ICR + IR full intensity): 9.5W (12V DC); 11.5W (PoE) |
Environment |
Operating Temperature |
-30°C to +60°C (-22°F to +140°F) |
Operating Humidity |
?95% |
Storage Temperature |
-30°C to +60°C (-22°F to +140°F) |
Ingress Protection |
IP67; IK10+50J |
Structure |
Casing |
Metal |
Dimensions |
209.4 mm × 212.0 mm × 103.1 mm
(8.2" × 8.3" × 4.1") (L × W × H)
|
Net Weight |
1365 g (3.0 lb) |
Gross Weight |
1465 g (3.2 lb) |
